Epson TM-U220B Receipt Printer – USB, PS, NE sensor, ECW

Description

Epson’s TM-U220 impact printers are compact, reliable and optimized for high-speed throughput. They offer all the easy-to-use features important to the retail, restaurant and hospitality industries and two-color printing to highlight special offers, kitchen orders and impactful logos.

In addition, the TM-U220 printers have been designed to be 100% compatible with existing systems that currently use a TM-U200 printer.

Technical Specifications

Print Type

Print method: 9-pin serial impact dot matrix
Technology: Serial Impact Dot Matrix

Font & Styles

Print Speed: 4.70 lps (40 columns, 16.00 cpi)
Column capacity receipt: Paper width 76 mm, 33 / 40
Character size: 1.2 mm (W) x 3.1 mm (H) / 1.6 mm (W) x 3.1 mm (H)
Character set: 95 Alphanumeric, 48 International, 128 x 12 Graphic
Characters per inch: 13.3 cpi / 16 cpi
Color Printing: Two colors

Paper

Paper Types: Receipt
Copy capability receipt: one copies plus one original
Paper size roll paper: 76.00 ± 0.50 (W) mm x dia 83.00 mm,
69.50 ± 0.50 (W) mm x dia 83.00 mm,
57.50 ± 0.50 (W) mm x dia 83.00 mm

Interfaces

Interfaces: Drawer kick-out, USB 1.1 Type B

Power

Power Supply: AC adapter, C
Operating Voltage: 24 V

General

Product dimensions: 160‎ x 248 x 139 mm (Width x Depth x Height)
Product weight: 2.5 kg
Color: Epson Cool White
Installation: horizontally, vertically with wall hanging bracket
Interface connectors: D.K.D. function (2 drivers)
Noise Level: Operation: 64 dB (A)
Supported Humidity: Operation 10% – 90%, Storage 10% – 90%
Supported Temperature: Storage -10° C – 50° C

Reliability

Reliability: 18,000,000 MCBF (Lines), 180,000 MTBF (Hours)
Auto Cutter Life: 800,000 Cuts
Printer Life: 7,500,000 lines

Standards Compliance

EMC Standards: CE marking
Safety standards: TÜV

Other Features

Cutter: Partial Cut
Sensors: Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor
Changeable interface: Yes
